HF0003221-Silicon Nitride Type High Pressure Ceramic Heating Element

·Rapid heating: Heating faster. up to 1000°c in 10 seconds
·Range of temperature:1000 °C/1832℉
·Small size / High watt density: High-watt density discharge allow high thermal efficiency.
·Long working life:10 years possible,90,000 hours
·High insulati
Description

Name Silicon Nitride Igniter
Model HF0003221
Material Silicon Nitride (Si3N4)
Voltage 400V
Power4 400W
Flange Ceramic/Stainless Steel/Copper/Customized
Temp Range 1000 °C/1832℉
Ignition Time  up to 1000°c in 10 seconds
Samples fee Please contact us for confirmation.
Packing Carton
Lead time 5 working days for samples; 12 working days for mass production
QC Strict quality control under SGS, ISO9001 and Intertek.
Certification BSCI, ISO9000/1400,BV TUV SGS FSC etc.
Applications
Biomass boiler/burner Pellet burners
Gas burner/stove Pellet boiler
Ignition of gas or oil Pellet burner
Pellet Stove Pellet BBQ grill
Stove fireplace Medical-Scientific
Wood pellet stove Heaters-Agricultural
Particle Burning Spark Igniters
Fuel cells EV heating
Gas appliances Glow plug
Petroleum equipment Cabin heater
Soldering iron Gas sensor
gas furnaces, DPF/Catalyst
gas boiler
·Rapid heating: Heating faster. up to 1000°c in 10 seconds
·Range of temperature:1000 °C/1832℉
·Small size / High watt density: High-watt density discharge allow high thermal efficiency.
·Long working life:10 years possible,90,000 hours
·High insulation
·Direct water and kerosene heating
·Vacuum environment
·Oxidation and chemical resistance
·Output switching
·Temperature sensing
